20Ton Swing Arm Click Press

20Ton Swing Arm Click Press

  • Categoryswing arm click press
  • SpecWarranty:1 Year
  • SpecVoltage:220v/380v or customized
  • SpecName:cutting/making machine
  • Description20Ton Swing Arm Click Press
Share

Description

Feature:
1. The die cutting press machine is applicable to cutting of various nonmetal materials by die cutter.
2. The use of time control allows for simple and convenient setting of cutter depth.
3. Operation with both hands, safe and reliable.
4. The inertial energy of flying wheel is used so that the energy consumption is low ans the operation stable.
5. The whole machine uses self-lubricating system to reduce wear and extend the service life of the machine

Model
GSB-2C/12
GSB-2C/16
GSB-2C/20
Maximum Cutting Force
120KN
200KN
250KN
Swing arm width
330*450mm
350*550mm
450*550mm
Stroke adjustment
5-55mm
5-75mm
5-75mm
Seissor speed
0.10m/s
0.10m/s
0.10m/s
